Application

Data centers are the backbone of the digital economy. Every second of downtime translates into massive revenue loss and reputational damage. At the heart of a data center’s electrical infrastructure lies the power distribution transformer – a component often overlooked but absolutely critical for reliability, efficiency, and safety. At Shandong Kerui Transformer Co., Ltd. , we deliver state-of-the-art dry-type transformers specifically engineered for the unique demands of modern data centers (Tier III / Tier IV).

Why Data Centers Demand Specialized Transformers
Unlike conventional buildings, data centers require transformers that excel in:

• Ultra-low noise – IT staff work near server rooms; noise regulations are strict.

• High energy efficiency – Reducing electrical losses directly lowers PUE (Power Usage Effectiveness).

• Fire safety – No flammable oil allowed; dry-type transformers are mandatory.

• Compact footprint – Space in data centers is at a premium.

• Low harmonic distortion & high short-circuit withstand – Protecting sensitive servers and UPS systems.

• 24/7 continuous operation – Maximum reliability with minimal maintenance.

Our Transformer Products for Data Centers

1. SCB Series – Epoxy Resin Cast Dry-Type Transformers
   – The first choice for indoor data center substations.
   – Fire-resistant, self-extinguishing, zero leakage risk.
   – Ultra-low noise design (≤42 dB).
   – Available in energy efficiency grades: SCB14 (Level 2) and SCB18 (Level 1).
   – Voltage range: 6KV, 10KV, 20KV, 35KV down to 0.4KV.

2. SGB Series – Non-Encapsulated Dry-Type Transformers (Class H Insulation)
   – Also known as open-type or gas-insulated dry-type.
   – Excellent overload capacity for unpredictable IT load surges.
   – Suitable for high ambient temperature environments.

3. Low-Voltage Isolation Transformers
   – For critical IT equipment, UPS bypass, and power conditioning.
   – Eliminate ground loops and provide galvanic isolation.

Key Advantages of Kerui Transformers for Data Centers

• Ultra-High Energy Efficiency: Our Level 1 (SCB18) and Level 2 (SCB14) transformers dramatically reduce no-load and load losses. For a 2MW data center, upgrading from SCB12 to SCB18 can save thousands of kWh annually, directly improving PUE by 0.01–0.03.

• Silent Operation: Special core stacking and vibration damping technology ensure noise levels as low as 40–42 dB, meeting the strictest requirements for IT rooms.

• Fire Safety: Class F1 fire performance – no toxic smoke, no fire propagation. Fully compliant with NFPA, IEC, and local building codes.

• High Short-Circuit Withstand: Robust winding design withstands sudden current surges without deformation.

• Compact & Clean: Smaller footprint and clean appearance fit easily into electrical rooms, skids, or containerized substations.

• Low Partial Discharge: Epoxy resin vacuum casting ensures long insulation life and high reliability.

Typical Data Center Applications

• Utility feed step-down: 35KV / 10KV to 0.4KV for main distribution.

• UPS input/output isolation: Isolation transformers for harmonic filtering and grounding.

• Redundant transformer banks: N+1 or 2N configurations for Tier IV uptime.

• Containerized / modular data centers: Compact box substations or skid-mounted transformers.

Case Example
A Tier III data center in the Middle East (UAE) replaced their existing dry-type transformers with our SCB18 (Level 1) units. The result: measured no-load loss reduced by 28%, PUE improved from 1.42 to 1.38, and noise dropped from 58 dB to 43 dB, greatly improving operator comfort.

Conclusion
In the world of data centers, every watt matters. Shandong Kerui Transformer Co., Ltd. offers proven, high-performance, and ultra-quiet dry-type transformers that maximize energy efficiency, ensure absolute safety, and guarantee continuous operation. Partner with us to build a greener, more reliable data center infrastructure.
